Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width

Automatic Rock Wool Panel Production Line with 40~120 meters/min Conveying Speed and 2800mm Swing Belt Width

Merknaam:	Greens
Modelnummer:	Steenwol wandpanelen die machine maken
Moq:	1
Prijs:	US $2000000-4000000
Betalingsvoorwaarden:	L/c, t/t

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

Hebei

Productnaam:

Vuurvaste hittebehoud geluidsisolatie steenwol wandpanelen die machine maken

Trefwoord:

Steenwol Bouwmuur Tussenlaag Interne isolatiemuur Steenwolproductielijn

Spanning:

380V of aangepast

Brengsnelheid:

40 tot 120 meter/min

Breedte van de zwaairiem:

2800 mm

Zwenkriemmotor:

4 kW (frequentiegestuurde motor)

Paneeldikte:

20250mm

Comité Dichtheid:

30-250 kg/m³

Markeren:

fireproof rock wool wall panels machine

heat preservation mineral wool production line

sound insulation rock wool board maker

Productbeschrijving

Fireproof Heat Preservation Sound Insulation Rock Wool Wall Panels Making Machine

This advanced production line combines fireproofing, heat preservation, and sound insulation capabilities for manufacturing high-quality rock wool wall panels with automated efficiency.

Key Specifications

Attribute	Value
Product Name	Drum Collection Machine Wool Collecting And Pendulum System Rock Wool Production Line
Voltage	380v Or Customized
Electric Control	PLC control
Condition	New
Conveying speed	40~120 meters/min
Swing belt width	2800mm
Swing belt motor	4kw (variable frequency motor)

Technical Specifications

Product Name: Rockwool Panel Production Line
Automatic Grade: Automatic
Voltage: 380V
Panel Thickness: 30-200mm
Felt Size: 1000mm (adjustable)
Panel Density: 30-200 Kg/m3
Applicable Industries: Manufacturing Plant, Retail, Construction works
Finished products: Rock wool board
Usage: Building Material Production

System Components

Slag and cotton separation system
Cotton collection mechanism
Screen cleaning device
Cotton lifting system
Automatic refueling and lubrication system
Automatic slag discharge device

The machine features a sturdy steel structure frame with bearing transmission system. The drum includes a mesh plate with installed negative pressure air induction chamber beneath. The fan creates negative pressure in the induction chamber, effectively pulling cotton fibers onto the stencil while filtering and emptying through the settling chamber.
