Full Automatic Gypsum Ceiling Tile Production Line with 1300mm Effective Laminating and 2-6 Million Sq.m/year Capacity

Full Automatic Gypsum Ceiling Tile Production Line with 1300mm Effective Laminating and 2-6 Million Sq.m/year Capacity

Merknaam: LVJOE
Modelnummer: 1300fm
Moq: 1 lijn
Prijs: US $20000-200000
Betalingsvoorwaarden: L/c, t/t
Toeleveringsvermogen: 10 regels per jaar
Gedetailleerde informatie
Plaats van herkomst:
Hebei, China (vasteland)
Certificering:
ISO CE
Productnaam:
Volautomatische geavanceerde dubbelzijdige lamineermachine Gipsplaat Plafondtegels die machine maken
Trefwoord:
plafondtegels maken
Afgewerkt bordtype:
PVC -gelamineerde gipsbord
Effectieve lamineren:
1300 mm
Elektrische regeling:
PLC -systeem
Productiecapaciteit:
2-6 miljoen m²/jaar
After-sales service:
Ingenieurs beschikbaar voor service
Lijmtype:
Waterlijm voor PVC -film
Verpakking Details:
Standaardpakking
Levering vermogen:
10 regels per jaar
Markeren:

1300mm Effective Laminating Gypsum Ceiling Tile Production Line

,

2-6 million Sq.m/year Production Capacity Gypsum Board Laminating Machine

,

Adjustable Speed 2-15m/min PVC Laminated Gypsum Board Machine

Productbeschrijving
Full Automatic Advanced Double Side Laminating Machine for Gypsum Board Ceiling Tiles
Product Overview

This advanced double side laminating machine is designed for producing PVC laminated gypsum boards used as ceiling tiles and partition wall panels. The fully automatic system handles fiber glass, paper, PVC film, and aluminum foil lamination with precision and efficiency.

Key Specifications
Attribute Value
Finished board type PVC laminated gypsum board
Effective laminating width 1300mm
Electric control PLC system
Production Capacity 2-6 million Sq.m/year
Speed 2-15m/min (adjustable)
After-sales Service Engineers available to service
Warranty 1 year
Glue type Water Glue for PVC film
Main Components
Automatic Gypsum Board Feeding Machine

The cylinder pushes gypsum boards from the stack lift platform to the conveyor roll for PVC and aluminum film lamination.

Max. Load-bearing: 3000kg
Stroke: 1500mm
Height range: 620mm - 2000mm
Platform size: 1200×2400mm
Automatic Cutting Machine

Features two cutting systems (vertical/longitudinal and horizontal) with dust collection, converting 1.2×2.4m boards into 603×603mm or 595×595mm tiles.

Cutting speed: 15m/min
Cutting knives: Vertical: 3 blades, Horizontal: 5 blades
Overall power: 17.15KW
Technical Specifications
  • Sheet thickness range: 5-30mm
  • Speed adjustment: Frequency conversion synchronous speed regulating
  • Annual capacity: 2-4 million Sq.m
  • Compatible film materials: PVC film, aluminum foils, decorative materials
  • Board materials: PVC baseboard, gypsum board, wood board, sectional board, PVC foam board
  • Stacking mode: 10 layers (4 packages/layer)
  • Lamination options: Double side (front and back simultaneously) or single side
  • Overall dimensions: 56000mm (L) × 9200mm (W)
