200T Pressure High Automatic Punch Press for Max 20mm Thickness Gypsum Board Perforation Machine

200T Pressure High Automatic Punch Press for Max 20mm Thickness Gypsum Board Perforation Machine

Merknaam: LVJOE
Modelnummer: LV-CK01
Moq: 1 Instellen
Prijs: US $20000-80000
Betalingsvoorwaarden: T/T,L/C
Toeleveringsvermogen: 50 sets per jaar
Gedetailleerde informatie
Plaats van herkomst:
China
Certificering:
ISO CE
Productnaam:
Commerciële techniekponspers gebruikt voor CNC automatische mechanische motorponsmachine voor gipspl
trefwoord:
Gatenboormachine voor MDF-platen
Druk:
80T, 160T, 200T
Gebruik:
Platen van gips, MDF, HPL, Perforatie van platen van cementvezels
Gaten:
Rond, vierkant
Automatisch niveau:
Hoge Automatisch
Dikte:
Max. 20 mm
Garantie:
1 jaar
Kerncomponenten:
Alarmsluiting
Machinetestrapport:
Mits
Verpakking Details:
PE -film ingepakt
Levering vermogen:
50 sets per jaar
Productbeschrijving
Commercial Engineering Punch Press
CNC Automatic Mechanical Motor Punching Machine For Gypsum Board
Product Overview
High-performance gypsum board drilling equipment designed for precision perforation in various building materials.
Product Specifications
Pressure 80T, 160T, 200T
Usage Gypsum Board, MDF, HPL, Fiber cement board perforation
Holes Round, Square
Automatic Level High automatic
Thickness Max. 20mm
Technical Specifications
  • Punching pressure: 200 ton
  • Stroke: 30 mm
  • Max mold height closed: 260mm
  • Number of strokes: 50 times/minute
  • Slide surface: 210*1100mm
  • Working table: 300*1670mm
  • Spacing of both pole: 1350mm (load the max board width 1220mm)
  • Power of main motor: 22kw
  • Power of servo motor: 2.6kw (brand: Zhejiang yifeng)
  • Feeding accuracy: ±1mm
  • Maximum feeding rate: 100mm
  • Maximum feeding thickness: 20mm
  • Gross weight of machine: 11000kg
  • Overall dimension: 2300*1500*2300(H*L*W)
Applications
This perforation machine is designed for creating holes in various materials including gypsum ceiling board, MgO board, MDF, HPL, Fiber cement board, and metal sheets. Custom hole shapes are available to meet specific requirements. Comprehensive operational training is provided.
Commercial Engineering Punch Press Machine for Gypsum Board
