200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

200T Pressure High Automatic Perforating Machine for Max 20mm Thickness Gypsum Board Punching

Merknaam:	LVJOE
Modelnummer:	LV-CK01
Moq:	1 Instellen
Prijs:	US $20000-80000
Toeleveringsvermogen:	50 sets per jaar

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

China

Certificering:

ISO CE

Productnaam:

Geluidsisolatieplaat Perforatieapparatuur Hoge snelheid gipskartonponsmachine

trefwoord:

Continue productie gipsplaatperforator

Druk:

80T, 160T, 200T

Gebruik:

Platen van gips, MDF, HPL, Perforatie van platen van cementvezels

Gaten:

Rond, vierkant

Automatisch niveau:

Hoge Automatisch

Dikte:

Max. 20 mm

Garantie:

1 jaar

Sollicitatie:

Binnenplafond en scheidingswand

Functie:

GEWOON

Verpakking Details:

PE -film ingepakt

Levering vermogen:

50 sets per jaar

Productbeschrijving

Sound Insulation Board Perforating Equipment High Speed Plaster Board Punch Machine

High-performance gypsum board drilling equipment designed for precision perforation in various building materials.

Product Specifications

Pressure	80T, 160T, 200T
Usage	Gypsum Board, MDF, HPL, Fiber cement board perforation
Holes	Round, Square
Automatic Level	High automatic
Thickness	Max. 20mm

Technical Specifications

Punching pressure: 200 ton
Stroke: 30 mm
Max mold height closed: 260mm
Number of strokes: 50 times/minute
Slide surface: 210*1100mm
Working table: 300*1670mm
Spacing of both pole: 1350mm (load the max board width 1220mm)
Power of main motor: 22kw
Power of servo motor: 2.6kw (brand: Zhejiang yifeng)
Feeding accuracy: ±1mm
Maximum feeding rate: 100mm
Maximum feeding thickness: 20mm
Gross weight of machine: 11000kg
Overall dimension: 2300*1500*2300(H*L*W)

Applications

This perforation machine is designed for creating holes in various materials including gypsum ceiling board, MgO board, MDF, HPL, Fiber cement board, and metal sheets. Custom hole shapes are available to meet specific requirements. Comprehensive operational training is provided.
